| Quantity: | |
|---|---|
Charging Voltage | 0–400 V |
Pulse Waveform | Wavefront 0.5 μs, Wave tail 6500 μs |
Pulse Frequency | 25 Hz (3 Hz with external Cs) |
Cutoff Time | 0.μs~16μs |
Charging Capacitor Cs | Range: 4.7 nF – 1000 nF (External supported, Max 10 μF) |
Wave tail resistance Rs | Range: 3.3 Ω – 4.7 kΩ (External supported) |
Wave tail resistance Rp | Range: 10 Ω – 15 kΩ (External supported) |
System Inductance L | 0–100 μH |
Load Capacitance | 0.47 nF – 168 nF (External supported) |
Charging Voltage | 0–400 V |
Pulse Waveform | Wavefront 0.5 μs, Wave tail 6500 μs |
Pulse Frequency | 25 Hz (3 Hz with external Cs) |
Cutoff Time | 0.μs~16μs |
Charging Capacitor Cs | Range: 4.7 nF – 1000 nF (External supported, Max 10 μF) |
Wave tail resistance Rs | Range: 3.3 Ω – 4.7 kΩ (External supported) |
Wave tail resistance Rp | Range: 10 Ω – 15 kΩ (External supported) |
System Inductance L | 0–100 μH |
Load Capacitance | 0.47 nF – 168 nF (External supported) |
